2．構造
以鎖止螺釘型和夾緊式型為標準。可能組合鎖止螺釘和夾緊式。
4．鎖止螺釘·夾緊式 緊扭矩和庫存軸孔徑一覽表
|
型號
|
固定法
|
尺寸
|
緊固扭矩
|
庫存軸孔徑
|
|
N?m
|
{kgf?cm}
|
3
|
4
|
5
|
6
|
6.35
|
8
|
9.525
|
10
|
12
|
14
|
16
|
20
|
25
|
30
|
|
EJC13
|
鎖止螺釘
|
M3
|
0.92
|
9.2
|
●
|
●
|
●
|
●
|
●
|
|
|
|
|
|
|
|
|
|
|
EJC19
|
鎖止螺釘
|
M3
|
0.92
|
9.2
|
|
●
|
●
|
●
|
●
|
●
|
|
|
|
|
|
|
|
|
|
EJC19
|
夾緊式
|
M2.5
|
1.21
|
12.3
|
|
●
|
●
|
●
|
●
|
●
|
|
|
|
|
|
|
|
|
|
EJC25
|
鎖止螺釘
|
M4
|
2.2
|
22.4
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
|
|
|
|
|
|
EJC25
|
夾緊式
|
M3
|
2.1
|
21.4
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
|
|
|
|
|
|
EJC33
|
鎖止螺釘
|
M4
|
2.2
|
22.4
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
|
|
|
|
EJC33
|
夾緊式
|
M3
|
2.1
|
21.4
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
|
|
|
|
EJC41
|
鎖止螺釘
|
M5
|
4.0
|
40.8
|
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
|
|
|
EJC41
|
夾緊式
|
M4
|
4.6
|
46.9
|
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
●
|
|
|
|
EJC51
|
夾緊式
|
M5
|
9.5
|
96.9
|
|
|
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
|
|
EJC57
|
夾緊式
|
M6
|
16.0
|
163
|
|
|
|
|
|
|
|
|
|
●
|
●
|
●
|
●
|
●
|
※把軸固定在輪轂上時,請參照上表中的緊固扭矩用扭矩扳手等工具將其緊固。
